Specifications

• Dimensions

  add remove
  • Length:
    105.1 in
  • Seat height, unladen:
    28.9 in
  • Ground clearance:
    4.9 in
  • Rake (steering head):
    26
  • Trail:
    4.0 in
  • Wheelbase:
    65.7 in
  • Tires, front specifications:
    MT 130/60B19 M/C 61H
  • Tires, rear specifications:
    P215/45R18 83T
  • Fuel Capacity:
    6.0 gal
  • Oil capacity:
    5 qt.
  • Weight, as shipped:
    1,199 lbs
  • Weight, in running order:
    1237 lb
  • Luggage capacity – volume:
    6.8 cu ft (0.19 m³)
  • Tire, type:
    Dunlop® Harley-Davidson Series, bias blackwall front and radial blackwall rear
• Engine

  add remove
  • Engine:
    Twin-Cooled™ Milwaukee-Eight® 114
  • Bore:
    4.0 in
  • Stroke:
    4.5 in
  • Displacement:
    113.99 in³
  • Compression ratio:
    10.5:1
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust:
    2-1-2 dual exhaust with tapered mufflers
• Performance

  add remove
  • Engine torque testing method:
    EC 134/2014
  • Engine torque:
    120.2 ft-lb
  • Engine torque (RPM):
    2500
  • Horsepower:
    93 HP / 69 kW @ 5020 rpm
  • Fuel economy testing method:
    EU 134/2014
  • Fuel economy:
    42 mpg (5.6 l/100km)
• Powertrain

  add remove
  • Primary drive:
    Chain, 34/46 ratio
  • Gear ratios (overall) 1st:
    10.534
  • Gear ratios (overall) 2nd:
    7.302
  • Gear ratios (overall) 3rd:
    5.423
  • Gear ratios (overall) 4th:
    4.392
  • Gear ratios (overall) 5th:
    3.741
  • Gear Ratios (overall) 6th:
    3.157
• Chassis

  add remove
  • Front fork:
    49mm dual bending valve
  • Rear shocks:
    Hand-adjustable emulsion rear suspension
  • Wheels, front type:
    Black, 7-spoke Cast Aluminum
  • Wheels, rear type:
    Black, 7-spoke Cast Aluminum
  • Brakes, type:
    Dual floating rotors (front), fixed rotor (rear)
  • Brakes, caliper type:
    Front: 32mm 4 piston fixed, Rear: floating 36mm piston integrated park brake
• Infotainment

  add remove
  • Infotainment system:
    Boom!™ Box GTS
  • Type:
    Full Color TFT
  • Watts per channel:
    25
  • Speakers:
    4
  • Speaker size:
    5.25 inch
  • Headset specifications (if equipped):
    16 - 64 ohms
  • AM:
    Standard
  • FM:
    Standard
  • SD Card, Flash Drive and MP3 — via USB Connection:
    Supported
  • Languages:
    English (US/UK) German Spanish (Mexico/Spain) French (Canada/France) Italian Portuguese (Portugal/Brazil) Russian Czech Polish Dutch Turkish Japanese Korean Chinese (Simplified) Siamese (Thai) Bahasa (Indonesian) Arabic
  • Hands-free mobile phone — via Bluetooth:
    Standard
  • Voice Recognition Languages: Phone functions only:
    Phone dependent
  • Voice Recognition Languages: Tuner / Media / Navigation:
    Phone dependent
  • Text-to-Speech (TTS) languages:
    Phone dependent
  • Rider / passenger intercom:
    Standard (Passenger Headset Sold Separately)
  • Vehicle information screen:
    Standard
  • USB:
    USB/MTP/iPod/iPhone
  • Bluetooth:
    Phone/Media Supported
