Specifications

• Dimensions

  add remove
  • Length:
    93.5 in
  • Seat height, unladen:
    26.2 in
  • Ground clearance:
    4.5 in
  • Rake (steering head):
    34
  • Trail:
    5.7 in
  • Wheelbase:
    66.7 in
  • Tires, front specifications:
    130/60B21,63H,BW
  • Tires, rear specifications:
    240/40R18,79V,BW
  • Fuel Capacity:
    5.0 gal
  • Oil capacity:
    5 qt.
  • Weight, as shipped:
    655 lbs
  • Weight, in running order:
    681 lb
  • Tire, type:
    Michelin® Scorcher 11, front and rear
• Engine

  add remove
  • Engine:
    Milwaukee-Eight® 117 Custom
  • Bore:
    4.1 in
  • Stroke:
    4.5 in
  • Displacement:
    117.35 in³
  • Compression ratio:
    10.3:1
  • Fuel system:
    Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust:
    2-into-2 staggered; catalyst in muffler
• Performance

  add remove
  • Engine torque testing method:
    EC 134/2014
  • Engine torque:
    126.1 ft-lb
  • Engine torque (RPM):
    3000
  • Horsepower:
    104 HP / 77 kW @ 4800 rpm
  • Lean angle, right (deg.):
    26.8
  • Lean angle, left (deg.):
    26.8
  • Fuel economy testing method:
    EU 134/2014
  • Fuel economy:
    49 mpg (4.8 l/100 km)
• Powertrain

  add remove
  • Primary drive:
    Chain, 34/46 ratio
  • Gear ratios (overall) 1st:
    9.311
  • Gear ratios (overall) 2nd:
    6.454
  • Gear ratios (overall) 3rd:
    4.793
  • Gear ratios (overall) 4th:
    3.882
  • Gear ratios (overall) 5th:
    3.307
  • Gear Ratios (overall) 6th:
    2.79
• Chassis

  add remove
  • Front fork:
    Dual-bending valve 49 mm telescopic with aluminum fork triple clamps; dual rate spring
  • Rear shocks:
    Hidden, free piston, coil-over monoshock; 43mm stroke; hydraulic preload adjustment
  • Wheels, front type:
    Gloss black, 26-spoke cast aluminum
  • Wheels, rear type:
    Gloss black, 26-spoke cast aluminum
  • Brakes, type:
    Front and rear black, Split 7-spoke floating rotors
  • Brakes, caliper type:
    4-piston fixed front and 2-piston floating rear
